Detroit Diesel GHG14 DDEC13 Electronic Controls Application & Installation Manual

This application & installation manual for the Detroit Diesel GHG14 DDEC13 Electronic Controls is a technical guideline for qualified personnel who design, build and install systems around these electronic controls.

The document is 380 pages long and is referenced as DDC-SVC-MAN-0127.

What's inside

• Attention/scope statement and abstract
• Introduction and safety precautions
• Hardware and wiring
• Inputs and outputs
• Features (selection of features and settings by application)
• Communication protocols
• Appendix A: Harness wiring diagram(s)
• Appendix B: Parameter lists
• Appendix C: Acronyms

Coverage

GHG14 (DDEC13).

Please note

This document is a guideline for qualified personnel and is intended to be used by vehicle manufacturers designing, manufacturing and installing ancillary systems supporting compatible GHG14 emission-compliant engines running DDEC13 electronic controls. It does not cover installation of the engine itself. Includes a California Proposition 65 warning and engine idle notice.

User help

1. Make sure it matches your machine. Look up your model and software/version details and compare them with the coverage above. Not sure? Send us those details and we will help you check before you buy.
2. Get the file. This is a digital PDF download. Nothing is shipped, so you can start using it as soon as you have the file.
3. Open it anywhere. Use any current PDF reader (Adobe Acrobat Reader, your browser, or a phone or tablet app). Save a copy to your computer and to a backup drive.
4. Find things quickly. Use the contents pages and your reader's search (Ctrl+F or Cmd+F) to jump to a component, fault code or specification. Print only the pages you need for the workshop.
5. Follow the intended use. This guide is for qualified personnel and assumes the engine itself is already installed. Check that your software version matches the one named above.
6. Safety first. Work on machinery, fuel and electrical systems carries real risk. Follow the document's safety notes, use suitable tools and supports, and comply with local rules. If a job is beyond your experience, use a qualified technician.

Detroit Diesel and all model names are trademarks of their respective owners and are used here only to identify compatibility. This store is an independent seller and is not affiliated with or endorsed by Detroit Diesel. For informational and maintenance use.
