Caterpillar C15, C16, C18 Truck Engine Disassembly & Assembly Workshop Service Manual

This is the Caterpillar factory Disassembly and Assembly manual (dated July 2008) for the C15, C16, and C18 Truck Engines, covering serial prefixes W1A1-Up, CJP1-Up, MDP1-Up, MEP1-Up, 6NZ1-Up, 7CZ1-Up, and 9NZ1-Up.

What's covered

• Fuel priming pump and fuel filter base
• Electronic unit injector
• Engine oil cooler
• Flywheel, front cover, gear group
• Accessory drive housing
• Valve mechanism
• Compression brake (Jake Brake)
• Camshaft
• Pistons and connecting rods

User help

1. Check the fit first. Compare your machine's serial number against the configuration or prefix shown above before you order. If you're not sure it matches, send us your serial number and we'll help you confirm.
2. Get the file. This is a digital PDF download. Nothing is shipped, so you can start using it as soon as you have the file.
3. Open it anywhere. Use any current PDF reader on a computer, tablet or phone, and keep a backup copy.
4. Find things quickly. Use the contents pages and your reader's search (Ctrl+F or Cmd+F) to jump to a component or procedure, and print only the pages you need for the workshop.
5. Work step by step. Follow the stated torque values and disassembly/assembly sequence, and use the specification and testing sections to confirm a fault before replacing parts.
6. Stay safe. Work on engines, hydraulics, fuel and electrical systems carries real risk. Follow the safety instructions in the document, use proper tools and support equipment, and follow local regulations.

Caterpillar and all model, engine and publication names are trademarks of their respective owners and are used here only to identify compatibility. This store is an independent seller and is not affiliated with or endorsed by Caterpillar. For informational and maintenance use.
